Ableton Live, Beap and Max for Live Basics 3: Beap as Audio Effects Chain

This post covers the basics of using Beap with Max for Live and Ableton Live. Max for Live is a bridge between Ableton Live and Cycling 74's Max. Max for Live allows for the creation of user-generated content in terms of Instruments, MIDI effects and Audio effects in Live. Beap is a set of modular devices / patches in Max by Stretta.




This tutorial will demonstrate how to build a simple audio effects chain within Beap and Max for Live.

Download the device created in this tutorial here: http://milkcrate.com.au/_other/downloads/M4L/beap/BEAP%20Example-%20Reverb%20Chorus%20LFO.amxd


Let's start off with a Live set that contains a MIDI track, a virtual instrument and some MIDI data, as shown below. Just something that can be used as a source for audio manipulation.


Add a Max for Live Audio Effects device to the output of the virtual instrument or audio track. Click on the edit button of the Audio Effects device.


Delete the comments and the connections between plugin~ and plugout~


Create a p object, and create two inlets and two outlets within the p object. Go back to the main patch, and connect the two outlets of the plugin~ to the p object and the two outlets of the p object to the two inlets of the plugout~ object. In this way, the p object will intercept and process any incoming audio, and send the processed audio out through the plugout~ object to the rest of the channel path within Live.


It is between the two inlets and the two outlets within the p object that the audio effects should be placed. These represent left and right signals. The following is one example, however please experiment to create your own examples. In this example, the L and R signal will be processed by a reverb, a chorus and a stereo filter controlled by an LFO. Please take this as an example; there are many, many different combinations that could be created.


Go to Beap > Effects > Gigaverb to add a gigaverb device. This is a reverb device with two inlets and two outlets, for left and right signals. Connect the two inlets within the p object to the left and right inlets of the gigaverb device respectively.


Go to Beap > Effects > Chorus to add a chorus device. Connect both of the inlets within the p object to the chorus signal input.


Go to Beap > LFO > CV LFO to add a CV LFO device.


Go to Beap > Filter > Ladder to add a ladder filter device. Connect the L outlet of the gigaverb device to the signal inlet of the ladder filter device. Connect the L outlet of the chrous device to the signal inlet of the ladder filter device. Connect the signal outlet of the CV LFO to the CV3 inlet of the ladder filter device. This is the left side of the stereo filter.


Create a second ladder filter. Go to Beap > Filter > Ladder to add a ladder filter device. Connect the R outlet of the gigaverb device to the signal inlet of the ladder filter device. Connect the R outlet of the chrous device to the signal inlet of the ladder filter device. Connect the signal outlet of the CV LFO to the CV3 inlet of the ladder filter device. This is the right side of the stereo filter.


Go to Beap > Mixer > Stereo Mixer to add a stereo mixer device. Connect the output of the stereo mixer to the outlets inside of the p object.


Save your main patch, and close it.

Return to Live, and the changes made to the Max Audio Effect device will be reflected. In Live, open the p object and change the parameters to alter how the sound is processed.

Ableton Live, Beap and Max for Live Basics 2: Basic FM MIDI Synth

This post covers the basics of using Beap with Max for Live and Ableton Live. Max for Live is a bridge between Ableton Live andCycling 74's Max. Max for Live allows for the creation of user-generated content in terms of Instruments, MIDI effects and Audio effects in Live. Beap is a set of modular devices / patches in Max by Stretta





This tutorial will demonstrate how to build a simple FM synthesiser with MIDI control, a filter with ADSR and volume controlled by both ADSR and velocity.

Download the device created in this tutorial here: http://milkcrate.com.au/_other/downloads/M4L/beap/BEAP%20Example-%20FM%20Synth.amxd

Let's start off with a blank, default Live set. Delete the two audio tracks as well as one of the two MIDI tracks.


In the Live browser, go the the Max for Live category, and add the default Max Instrument device to the MIDI track. A Max Instrument takes MIDI data as an input and sends a left and right audio signal as an output. The instrument that is built will generate an audio signal that is based on the incoming MIDI data.


Click on the edit button, which is the third on the right in the title bar of the Max Instrument device. Assuming that Max 7 is installed, the Max environment will open up and the Max Instrument patch will be editable.


Delete the comments. These are unneeded. Select the comments and press delete.


The midiin object represents the MIDI data coming into the device from the Live MIDI track or MIDI device. The plugout~ object represents audio going out of the device.



Max for Live devices are limited in terms of screen real estate. The light gray area represents the vertical limit when viewed inside of Live. Beap objects, however, are quite large and take up plenty of screen real estate. As a result, this patch will include a "sub patch" - a second window that can be opened up within Live, and can be as large as required. In Max, create a new object by pressing the n key. The new object will simply be called p. This is short for sub patch. Type in p into the object creation box. A p object will be created, and a new window that represents the contents of the p object will open automatically.



The p object does not have any inputs or outputs; it is currently impossible to send MIDI data to the p object by connecting patch cables, or audio out of it. Inlets and outlets are required. Create a new object by pressing the n key in the sub patch. Type in the word inlet, and hit return. The object will turn into a triangle that represents signals coming into the patch via an input going into the p object. This single inlet will represent MIDI data coming into the sub patch.


Create two outlet objects. These outlets represent the audio left and audio right signals coming out of the sub patch.


In order to make use of MIDI data with Beap devices, a method for converting MIDI data into CV signals, gate signals and trigger signals is required. Go to Beap > MIDI > MIDI to Signal and double click to add a Beap MIDI to signal device. The MIDI to signal device takes MIDI data as an input, and outputs CV, gate and trigger signals. The 1v/oct signal outlet corresponds to the frequency of incoming notes. The Gate and Trig outlets indicate whether or not a note has been played, and how long the note is held for. The Vel outlet corresponds to a signal level for the velocity (which can thus be mapped to other elements within Beap) and the Mod outlet corresponds to changes in the modulation wheel data. For the purposes of this tutorial, only the 1v/oct, Gate and Vel outlets are used. Additionally, click back to the top level patcher, and connect the midiin object to the inlet of the p object, and two outlets of the p object to the inlets of the plugin~ object. Return to the inside of the p object once this has been done.


Go to Beap > Oscillator > FM Oscillator and double click to add a Beap FM oscillator device. This is a basic single carrier / single modulator type FM oscillator with minimal settings of ratio and depth. The depth can be controlled via a CV signal. Connect the 1v/oct output of the MIDI to signal device to the 1v/oct input of the FM oscillator. As a result, the frequency of the FM synthesiser will be controlled by incoming MIDI notes. Feel free to experiment with other oscillators, too!


Go to Beap > Filter > Diode Ladder and double click to add a Beap diode ladder type filter device. This is similar to the filter used in the previous tutorial, however with a somewhat harsher sound. Once again, there are three CV inputs, a signal input and a signal output.


Go to Beap > Envelope > ADSR and double click to add an ADSR envelope generator device. This is the same ADSR envelope generator as used in the previous tutorial. Connect the gate outlet of the MIDI to signal device to the gate inlet of the ADSR device. Every time a new MIDI note is detected, a new ADSR envelope is generated. Connect the signal outlet of the ADSR envelope to the CV3 inlet of the diode ladder. The ADSR envelope will now control the frequency of the diode ladder, assuming that the CV3 percentage parameter is set to a value greater than 0%.


Create a second ADSR envelope. Go to Beap > Envelope > ADSR and double click to add an ADSR envelope generator device. This is the same ADSR envelope generator as used in the previous tutorial. Connect the gate outlet of the MIDI to signal device to the gate inlet of the ADSR device. Every time a new MIDI note is detected, a new ADSR envelope is generated. This second ADSR device will be used to shape the volume of the signal.


Go to Beap > Level > VCA and double click to add a VCA device. A VCA is a voltage controlled amplifier, whereby a signal can have the volume modulated by using a second signal or control voltage. A VCA has two inputs - a signal and a CV input - and one output - a signal output. The signal input is the signal that is to be modulated. The CV input is the control voltage signal that is to be used to control the volume modulation. Connect the signal output of the diode ladder to the signal input of the VCA. This is the audible signal. Connect the signal output of the second ADSR to the CV input of the VCA. This is the control signal used to change the volume of the audible signal. As a result, the ADSR will be used to control the volume of the synth for every note that is received.


Create a second VCA. Go to Beap > Level > VCA and double click to add a VCA device. Connect the signal output of the first VCA to the signal input of the second VCA. This is the audible signal. Connect the Vel output of the MIDI to signal device to the CV input of the second VCA. This is the control signal used to change the volume of the audible signal. As a result, the velocity will be used to scale the volume of the synth.


Go to Beap > Effects > Sync delay and double click to add a sync delay effect device. The sync delay device is a rhythmic subdivision-oriented delay with feedback and filters. Connect the signal output of the second VCA to the L and R inlets of the sync delay device.


Go to Beap > Mixer > Stereo Mixer and double click to add a stereo mixer device. The stereo mixer device can take up to four stereo (left and right) audio signals, and mix them down to one stereo (left and right) audio signal. Connect the left and right outlets of the sync delay to the left and right inlets of the stereo mixer. Connect the outlets of the stereo mixer to the two outlet objects inside of the p object.



Save your main patch, and close it.

Return to Live, and the changes made to the Max instrument device will be reflected. Within Live, open up the p object by double clicking on it. From there, adjust parameters while playing MIDI data into the synth to experiment with setting up a basic FM patch.

Ableton Live, Beap and Max for Live Basics 1: Step Sequencer

This post covers the basics of using Beap with Max for Live and Ableton Live. Max for Live is a bridge between Ableton Live and Cycling 74's Max. Max for Live allows for the creation of user-generated content in terms of Instruments, MIDI effects and Audio effects in Live. Beap is a set of modular devices / patches in Max by Stretta.

Note that this particular tutorial is based on the 'Beap: Getting Started' video by Stretta.




This tutorial will demonstrate how to build a simple step sequencer that controls an oscillator going into a filter with an envelope.

Download the device made in this tutorial here: http://milkcrate.com.au/_other/downloads/M4L/beap/BEAP%20Example-%20Sequencer.amxd


Let's start off with a blank, default Live set.


Delete any unused audio and MIDI tracks.


In the Live browser, go the the Max for Live category, and add the default Max Audio Effect device to a track. A Max audio effect takes a left and right audio signal as an input and sends a left and right audio signal as an output.


Click on the edit button, which is the third on the right in the title bar of the Max Audio Effect device. Assuming that Max 7 is installed, the Max environment will open up and the Max Audio Effect patch will be editable. In Max, to switch between Lock and Edit modes, press command e. In Edit mode, new objects can be added, current objects can be deleted and changed. In Lock mode, parameters of objects can be changed by simply clicking and dragging. To change parameters of an object in Edit mode, hold down command and click and drag.


Delete the comments. These are unneeded. Select the comments and press delete.


The plugin~ object represents the audio coming into the device. The plugout~ object represents audio going out of the device.


Delete the two signal cables between the plugin~ and the plugout~ objects. Between these points is where the functionality of the patch will reside.


Max for Live devices are limited in terms of screen real estate. The light gray area represents the vertical limit when viewed inside of Live. Beap objects, however, are quite large and take up plenty of screen real estate. As a result, this patch will include a "sub patch" - a second window that can be opened up within Live, and can be as large as required. In Max, create a new object by pressing the n key. The new object will simply be called p. This is short for sub patch. Type in p into the object creation box. A p object will be created, and a new window that represents the contents of the p object will open automatically.


The p object does not have any inputs or outputs; it is currently impossible to send signal to and from the p object by connecting patch cables. Inlets and outlets are required. Create a new object by pressing the n key in the sub patch. Type in the word inlet, and hit return. The object will turn into a triangle that represents signals coming into the patch via an input going into the p object.


Create a second inlet. This will be for left and right audio signals coming into the patch.


Create two outlet objects. This will be for left and right audio signals going out of the patch.


Resize the patch window so that there is plenty of room to add Beap objects.


Click back to the main window, and resize the p object. Note that there are now two inlets and two outlets as part of the p object. This is due to the creation of the inlets and outlets within the sub patch window.


Patch the plugin~ object to the p object.  Patch the p object to the plugout~ object.


Open the p object again by command double-clicking on it.


Create a Beap device. These can be found in the b icon on the left had side tool bar, below the v icon and above the star icon. Note that Beap devices are categorised into types.


Go to Beap > Mixers > Signal Mixer and double click to add a Beap signal mixer device. The signal mixer can be used to balance and mix signals within a Beap patch.


Patch the output of the signal mixer device to the outlets of the sub patch.


Go to Beap > Oscillators > Oscillator and double click to add a Beap oscillator device. This is a basic oscillator. Feel free to experiment with other oscillator types for other waveforms or more interesting sounds.


Go to Beap > Filters > Ladder and double click to add a Beap ladder filter device. This is a basic low pass filter. Feel free to experiment with other filter types.


Connect the signal output of the oscillator to the signal input of the ladder. Connect the signal output of the ladder to the in 1 signal input of the signal mixer.


Go to Beap > Sequencer > Sequencer and double click to add a Beap step sequencer device. This is a basic sequencer. Feel free to experiment with other sequencer types.


Go to Beap > Envelope > ADSR and double click to add a Beap ADSR envelope device. This is a basic ADSR envelope. Feel free to experiment with other envelope types.


The left output of the sequencer is labeled CV. This is short for control voltage, and represents a signal that can be used to control and modulate other control voltage devices. Connect the CV output of the gate to the CV 1 input of the oscillator.


The right output of the sequencer is labeled gate. The gate signal indicates whenever a new step in the sequencer is played back. This gate signal can be used as a source to drive other objects (usually related to time / rhythm in some way) from the sequencer. Connect the gate output of the sequencer to the gate input of the ADSR. Every time a new step is played back from the sequencer, the gate output will now trigger a new ADSR envelope signal. Connect the signal output of the ADSR to the CV3 input of the ladder filter.


Go to Beap > LFO > CV LFO and double click to add a Beap CV LFO device. This is a basic control voltage low frequency oscillator.


Connect the signal outlet of the CV LFO to the CV 1 input of the ladder. The ladder filter is now being controlled by the ADSR as well as the LFO, assuming that the percentages for CV1 and CV3 are set above 0% in the ladder filter device.


Save your main patch, and close it.

Return to Live, and the changes made to the Max audio effect device will be reflected.
